Most Common 14-inch Tire Sizes
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 155/65R14 | 21.9x6.1R14 | 21.9" (557.1 mm) | 6.1" (155 mm) | 14" x 4.5-5.5" | 4" (100.8 mm) | 68.9" (1750.2 mm) | 919.5 (571.4) |
| 165/60R14 | 21.8x6.5R14 | 21.8" (553.6 mm) | 6.5" (165 mm) | 14" x 4.5-6.0" | 3.9" (99 mm) | 68.5" (1739.2 mm) | 925.3 (575) |
| 175/65R14 | 23x6.9R14 | 23" (583.1 mm) | 6.9" (175 mm) | 14" x 5.0-6.0" | 4.5" (113.8 mm) | 72.1" (1831.9 mm) | 878.5 (545.9) |
| 185/60R14 | 22.7x7.3R14 | 22.7" (577.6 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 4.4" (111 mm) | 71.4" (1814.6 mm) | 886.9 (551.1) |
| 185/65R14 | 23.5x7.3R14 | 23.5" (596.1 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 4.7" (120.3 mm) | 73.7" (1872.7 mm) | 859.4 (534) |
| 195/60R14 | 23.2x7.7R14 | 23.2" (589.6 mm) | 7.7" (195 mm) | 14" x 5.5-7.0" | 4.6" (117 mm) | 72.9" (1852.3 mm) | 868.8 (539.9) |
| 195/70R14 | 24.7x7.7R14 | 24.7" (628.6 mm) | 7.7" (195 mm) | 14" x 5.0-6.5" | 5.4" (136.5 mm) | 77.7" (1974.8 mm) | 814.9 (506.4) |
| 205/60R14 | 23.7x8.1R14 | 23.7" (601.6 mm) | 8.1" (205 mm) | 14" x 5.5-7.0" | 4.8" (123 mm) | 74.4" (1890 mm) | 851.5 (529.1) |
| 205/70R14 | 25.3x8.1R14 | 25.3" (642.6 mm) | 8.1" (205 mm) | 14" x 5.0-7.0" | 5.6" (143.5 mm) | 79.5" (2018.8 mm) | 797.2 (495.3) |
| 215/70R14 | 25.9x8.5R14 | 25.9" (656.6 mm) | 8.5" (215 mm) | 14" x 5.5-7.0" | 5.9" (150.5 mm) | 81.2" (2062.8 mm) | 780.2 (484.8) |
14-Inch Rims Size Chart
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 105/70R14 | 19.8x4.1R14 | 19.8" (502.6 mm) | 4.1" (105 mm) | 14" x n/a | 2.9" (73.5 mm) | 62.2" (1579 mm) | 1019.2 (633.3) |
| 115/70R14 | 20.3x4.5R14 | 20.3" (516.6 mm) | 4.5" (115 mm) | 14" x n/a | 3.2" (80.5 mm) | 63.9" (1622.9 mm) | 991.6 (616.2) |
| 135/80R14 | 22.5x5.3R14 | 22.5" (571.6 mm) | 5.3" (135 mm) | 14" x n/a | 4.3" (108 mm) | 70.7" (1795.7 mm) | 896.2 (556.9) |
| 135/90R14 | 23.6x5.3R14 | 23.6" (598.6 mm) | 5.3" (135 mm) | 14" x n/a | 4.8" (121.5 mm) | 74" (1880.6 mm) | 855.8 (531.8) |
| 145/65R14 | 21.4x5.7R14 | 21.4" (544.1 mm) | 5.7" (145 mm) | 14" x 4.0-5.0" | 3.7" (94.3 mm) | 67.3" (1709.3 mm) | 941.5 (585) |
| 145/80R14 | 23.1x5.7R14 | 23.1" (587.6 mm) | 5.7" (145 mm) | 14" x 3.5-5.0" | 4.6" (116 mm) | 72.7" (1846 mm) | 871.8 (541.7) |
| 155/65R14 | 21.9x6.1R14 | 21.9" (557.1 mm) | 6.1" (155 mm) | 14" x 4.5-5.5" | 4" (100.8 mm) | 68.9" (1750.2 mm) | 919.5 (571.4) |
| 155/80R14 | 23.8x6.1R14 | 23.8" (603.6 mm) | 6.1" (155 mm) | 14" x 4.0-5.0" | 4.9" (124 mm) | 74.7" (1896.3 mm) | 848.7 (527.4) |
| 125/70R14 | 20.9x4.9R14 | 20.9" (530.6 mm) | 4.9" (125 mm) | 14" x n/a | 3.4" (87.5 mm) | 65.6" (1666.9 mm) | 965.5 (599.9) |
| 165/55R14 | 21.1x6.5R14 | 21.1" (537.1 mm) | 6.5" (165 mm) | 14" x 4.5-6.0" | 3.6" (90.8 mm) | 66.4" (1687.3 mm) | 953.8 (592.6) |
| 165/60R14 | 21.8x6.5R14 | 21.8" (553.6 mm) | 6.5" (165 mm) | 14" x 4.5-6.0" | 3.9" (99 mm) | 68.5" (1739.2 mm) | 925.3 (575) |
| 165/70R14 | 23.1x6.5R14 | 23.1" (586.6 mm) | 6.5" (165 mm) | 14" x 4.0-5.5" | 4.5" (115.5 mm) | 72.6" (1842.9 mm) | 873.3 (542.6) |
| 165/80R14 | 24.4x6.5R14 | 24.4" (619.6 mm) | 6.5" (165 mm) | 14" x 4.0-5.5" | 5.2" (132 mm) | 76.6" (1946.5 mm) | 826.8 (513.7) |
| 155/70R14 | 22.5x6.1R14 | 22.5" (572.6 mm) | 6.1" (155 mm) | 14" x 4.0-5.0" | 4.3" (108.5 mm) | 70.8" (1798.9 mm) | 894.6 (555.9) |
| 175/65R14 | 23x6.9R14 | 23" (583.1 mm) | 6.9" (175 mm) | 14" x 5.0-6.0" | 4.5" (113.8 mm) | 72.1" (1831.9 mm) | 878.5 (545.9) |
| 175/70R14 | 23.6x6.9R14 | 23.6" (600.6 mm) | 6.9" (175 mm) | 14" x 4.5-6.0" | 4.8" (122.5 mm) | 74.3" (1886.8 mm) | 852.9 (530) |
| 175/75R14 | 24.3x6.9R14 | 24.3" (618.1 mm) | 6.9" (175 mm) | 14" x 4.5-6.0" | 5.2" (131.3 mm) | 76.4" (1941.8 mm) | 828.8 (515) |
| 175/80R14 | 25x6.9R14 | 25" (635.6 mm) | 6.9" (175 mm) | 14" x 4.5-6.0" | 5.5" (140 mm) | 78.6" (1996.8 mm) | 806 (500.8) |
| 165/65R14 | 22.4x6.5R14 | 22.4" (570.1 mm) | 6.5" (165 mm) | 14" x 4.5-6.0" | 4.2" (107.3 mm) | 70.5" (1791 mm) | 898.6 (558.3) |
| 185/70R14 | 24.2x7.3R14 | 24.2" (614.6 mm) | 7.3" (185 mm) | 14" x 4.5-6.0" | 5.1" (129.5 mm) | 76" (1930.8 mm) | 833.5 (517.9) |
| 185/75R14 | 24.9x7.3R14 | 24.9" (633.1 mm) | 7.3" (185 mm) | 14" x 4.5-6.0" | 5.5" (138.8 mm) | 78.3" (1988.9 mm) | 809.1 (502.8) |
| 185/80R14 | 25.7x7.3R14 | 25.7" (651.6 mm) | 7.3" (185 mm) | 14" x 4.5-6.0" | 5.8" (148 mm) | 80.6" (2047.1 mm) | 786.2 (488.5) |
| 155/55R14 | 20.7x6.1R14 | 20.7" (526.1 mm) | 6.1" (155 mm) | 14" x 4.5-5.5" | 3.4" (85.3 mm) | 65.1" (1652.8 mm) | 973.7 (605) |
| 175/60R14 | 22.3x6.9R14 | 22.3" (565.6 mm) | 6.9" (175 mm) | 14" x 5.0-6.0" | 4.1" (105 mm) | 70" (1776.9 mm) | 905.7 (562.8) |
| 195/65R14 | 24x7.7R14 | 24" (609.1 mm) | 7.7" (195 mm) | 14" x 5.5-7.0" | 5" (126.8 mm) | 75.3" (1913.5 mm) | 841 (522.6) |
| 195/70R14 | 24.7x7.7R14 | 24.7" (628.6 mm) | 7.7" (195 mm) | 14" x 5.0-6.5" | 5.4" (136.5 mm) | 77.7" (1974.8 mm) | 814.9 (506.4) |
| 195/75R14 | 25.5x7.7R14 | 25.5" (648.1 mm) | 7.7" (195 mm) | 14" x 5.0-6.5" | 5.8" (146.3 mm) | 80.2" (2036.1 mm) | 790.4 (491.1) |
| 195/80R14 | 26.3x7.7R14 | 26.3" (667.6 mm) | 7.7" (195 mm) | 14" x 5.0-6.5" | 6.1" (156 mm) | 82.6" (2097.3 mm) | 767.3 (476.8) |
| 185/50R14 | 21.3x7.3R14 | 21.3" (540.6 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 3.6" (92.5 mm) | 66.9" (1698.3 mm) | 947.6 (588.8) |
| 185/55R14 | 22x7.3R14 | 22" (559.1 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 4" (101.8 mm) | 69.2" (1756.5 mm) | 916.2 (569.3) |
| 205/65R14 | 24.5x8.1R14 | 24.5" (622.1 mm) | 8.1" (205 mm) | 14" x 5.5-7.5" | 5.2" (133.3 mm) | 76.9" (1954.4 mm) | 823.5 (511.7) |
| 205/75R14 | 26.1x8.1R14 | 26.1" (663.1 mm) | 8.1" (205 mm) | 14" x 5.0-7.0" | 6.1" (153.8 mm) | 82" (2083.2 mm) | 772.5 (480) |
| 165/50R14 | 20.5x6.5R14 | 20.5" (520.6 mm) | 6.5" (165 mm) | 14" x n/a | 3.2" (82.5 mm) | 64.4" (1635.5 mm) | 984 (611.4) |
| 215/60R14 | 24.2x8.5R14 | 24.2" (613.6 mm) | 8.5" (215 mm) | 14" x 6.0-7.5" | 5.1" (129 mm) | 75.9" (1927.7 mm) | 834.9 (518.8) |
| 205/70R14 | 25.3x8.1R14 | 25.3" (642.6 mm) | 8.1" (205 mm) | 14" x 5.0-7.0" | 5.6" (143.5 mm) | 79.5" (2018.8 mm) | 797.2 (495.3) |
| 205/45R14 | 21.3x8.1R14 | 21.3" (540.1 mm) | 8.1" (205 mm) | 14" x 6.5-7.5" | 3.6" (92.3 mm) | 66.8" (1696.8 mm) | 948.5 (589.4) |
| 185/60R14 | 22.7x7.3R14 | 22.7" (577.6 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 4.4" (111 mm) | 71.4" (1814.6 mm) | 886.9 (551.1) |
| 185/65R14 | 23.5x7.3R14 | 23.5" (596.1 mm) | 7.3" (185 mm) | 14" x 5.0-6.5" | 4.7" (120.3 mm) | 73.7" (1872.7 mm) | 859.4 (534) |
| 225/60R14 | 24.6x8.9R14 | 24.6" (625.6 mm) | 8.9" (225 mm) | 14" x 6.0-8.0" | 5.3" (135 mm) | 77.4" (1965.4 mm) | 818.8 (508.8) |
| 225/75R14 | 27.3x8.9R14 | 27.3" (693.1 mm) | 8.9" (225 mm) | 14" x n/a | 6.6" (168.8 mm) | 85.7" (2177.4 mm) | 739.1 (459.3) |
| 235/70R14 | 27x9.3R14 | 27" (684.6 mm) | 9.3" (235 mm) | 14" x n/a | 6.5" (164.5 mm) | 84.7" (2150.7 mm) | 748.3 (465) |
| 245/70R14 | 27.5x9.6R14 | 27.5" (698.6 mm) | 9.6" (245 mm) | 14" x n/a | 6.8" (171.5 mm) | 86.4" (2194.7 mm) | 733.3 (455.6) |
| 225/40R14 | 21.1x8.9R14 | 21.1" (535.6 mm) | 8.9" (225 mm) | 14" x 7.5-9.0" | 3.5" (90 mm) | 66.2" (1682.6 mm) | 956.4 (594.3) |
| 215/75R14 | 26.7x8.5R14 | 26.7" (678.1 mm) | 8.5" (215 mm) | 14" x 5.5-7.0" | 6.3" (161.3 mm) | 83.9" (2130.3 mm) | 755.4 (469.4) |
| 265/50R14 | 24.4x10.4R14 | 24.4" (620.6 mm) | 10.4" (265 mm) | 14" x 7.0-10.0" | 5.2" (132.5 mm) | 76.8" (1949.7 mm) | 825.4 (512.9) |
| 275/60R14 | 27x10.8R14 | 27" (685.6 mm) | 10.8" (275 mm) | 14" x 7.5-9.5" | 6.5" (165 mm) | 84.8" (2153.9 mm) | 747.2 (464.3) |
| 215/65R14 | 25x8.5R14 | 25" (635.1 mm) | 8.5" (215 mm) | 14" x 6.0-7.5" | 5.5" (139.8 mm) | 78.6" (1995.2 mm) | 806.6 (501.2) |
| 215/70R14 | 25.9x8.5R14 | 25.9" (656.6 mm) | 8.5" (215 mm) | 14" x 5.5-7.0" | 5.9" (150.5 mm) | 81.2" (2062.8 mm) | 780.2 (484.8) |
| 255/35R14 | 21x10R14 | 21" (534.1 mm) | 10" (255 mm) | 14" x 8.5-10.0" | 3.5" (89.3 mm) | 66.1" (1677.9 mm) | 959.1 (596) |
| 195/55R14 | 22.4x7.7R14 | 22.4" (570.1 mm) | 7.7" (195 mm) | 14" x 5.5-7.0" | 4.2" (107.3 mm) | 70.5" (1791 mm) | 898.6 (558.3) |
| 195/60R14 | 23.2x7.7R14 | 23.2" (589.6 mm) | 7.7" (195 mm) | 14" x 5.5-7.0" | 4.6" (117 mm) | 72.9" (1852.3 mm) | 868.8 (539.9) |
| 205/50R14 | 22.1x8.1R14 | 22.1" (560.6 mm) | 8.1" (205 mm) | 14" x 5.5-7.5" | 4" (102.5 mm) | 69.3" (1761.2 mm) | 913.8 (567.8) |
| 205/60R14 | 23.7x8.1R14 | 23.7" (601.6 mm) | 8.1" (205 mm) | 14" x 5.5-7.0" | 4.8" (123 mm) | 74.4" (1890 mm) | 851.5 (529.1) |
| 205/55R14 | 22.9x8.1R14 | 22.9" (581.1 mm) | 8.1" (205 mm) | 14" x 5.5-7.5" | 4.4" (112.8 mm) | 71.9" (1825.6 mm) | 881.6 (547.8) |
| 225/55R14 | 23.7x8.9R14 | 23.7" (603.1 mm) | 8.9" (225 mm) | 14" x 6.0-8.0" | 4.9" (123.8 mm) | 74.6" (1894.7 mm) | 849.4 (527.8) |
| 245/50R14 | 23.6x9.6R14 | 23.6" (600.6 mm) | 9.6" (245 mm) | 14" x 6.5-9.5" | 4.8" (122.5 mm) | 74.3" (1886.8 mm) | 852.9 (530) |
| 235/60R14 | 25.1x9.3R14 | 25.1" (637.6 mm) | 9.3" (235 mm) | 14" x 6.5-8.5" | 5.6" (141 mm) | 78.9" (2003.1 mm) | 803.4 (499.2) |
| 225/70R14 | 26.4x8.9R14 | 26.4" (670.6 mm) | 8.9" (225 mm) | 14" x 6.0-7.5" | 6.2" (157.5 mm) | 82.9" (2106.8 mm) | 763.9 (474.7) |
| 225/45R14 | 22x8.9R14 | 22" (558.1 mm) | 8.9" (225 mm) | 14" x 7.0-8.5" | 4" (101.3 mm) | 69" (1753.3 mm) | 917.9 (570.3) |
| 225/50R14 | 22.9x8.9R14 | 22.9" (580.6 mm) | 8.9" (225 mm) | 14" x 6.5-7.0" | 4.4" (112.5 mm) | 71.8" (1824 mm) | 882.3 (548.2) |
| 245/60R14 | 25.6x9.6R14 | 25.6" (649.6 mm) | 9.6" (245 mm) | 14" x 7.0-8.5" | 5.8" (147 mm) | 80.3" (2040.8 mm) | 788.6 (490) |
| 255/60R14 | 26x10R14 | 26" (661.6 mm) | 10" (255 mm) | 14" x 7.0-9.0" | 6" (153 mm) | 81.8" (2078.5 mm) | 774.3 (481.1) |
| 255/55R14 | 25x10R14 | 25" (636.1 mm) | 10" (255 mm) | 14" x 7.0-9.0" | 5.5" (140.3 mm) | 78.7" (1998.4 mm) | 805.3 (500.4) |
| 265/60R14 | 26.5x10.4R14 | 26.5" (673.6 mm) | 10.4" (265 mm) | 14" x 7.5-9.5" | 6.3" (159 mm) | 83.3" (2116.2 mm) | 760.5 (472.6) |
| 175/50R14 | 20.9x6.9R14 | 20.9" (530.6 mm) | 6.9" (175 mm) | 14" x 5.0-6.0" | 3.4" (87.5 mm) | 65.6" (1666.9 mm) | 965.5 (599.9) |
| 195/40R14 | 20.1x7.7R14 | 20.1" (511.6 mm) | 7.7" (195 mm) | 14" x 6.5-7.5" | 3.1" (78 mm) | 63.3" (1607.2 mm) | 1001.3 (622.2) |
| 195/45R14 | 20.9x7.7R14 | 20.9" (531.1 mm) | 7.7" (195 mm) | 14" x 6.0-7.5" | 3.5" (87.8 mm) | 65.7" (1668.5 mm) | 964.5 (599.3) |
| 215/40R14 | 20.8x8.5R14 | 20.8" (527.6 mm) | 8.5" (215 mm) | 14" x 7.0-8.5" | 3.4" (86 mm) | 65.3" (1657.5 mm) | 970.9 (603.3) |
