Most Common 17-inch Tire Sizes
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 225/45R17 | 25x8.9R17 | 25" (634.3 mm) | 8.9" (225 mm) | 17" x 7.0-8.5" | 4" (101.3 mm) | 78.5" (1992.7 mm) | 807.6 (501.8) |
| 245/45R17 | 25.7x9.6R17 | 25.7" (652.3 mm) | 9.6" (245 mm) | 17" x 7.5-9.0" | 4.3" (110.3 mm) | 80.7" (2049.3 mm) | 785.3 (488) |
| 205/50R17 | 25.1x8.1R17 | 25.1" (636.8 mm) | 8.1" (205 mm) | 17" x 5.5-7.5" | 4" (102.5 mm) | 78.8" (2000.6 mm) | 804.4 (499.9) |
| 215/55R17 | 26.3x8.5R17 | 26.3" (668.3 mm) | 8.5" (215 mm) | 17" x 6.0-7.5" | 4.7" (118.3 mm) | 82.7" (2099.5 mm) | 766.5 (476.3) |
| 235/55R17 | 27.2x9.3R17 | 27.2" (690.3 mm) | 9.3" (235 mm) | 17" x 6.5-8.5" | 5.1" (129.3 mm) | 85.4" (2168.6 mm) | 742.1 (461.1) |
| 225/55R17 | 26.7x8.9R17 | 26.7" (679.3 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 4.9" (123.8 mm) | 84" (2134.1 mm) | 754.1 (468.6) |
| 235/45R17 | 25.3x9.3R17 | 25.3" (643.3 mm) | 9.3" (235 mm) | 17" x 7.5-9.0" | 4.2" (105.8 mm) | 79.6" (2021 mm) | 796.3 (494.8) |
| 225/60R17 | 27.6x8.9R17 | 27.6" (701.8 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 5.3" (135 mm) | 86.8" (2204.8 mm) | 729.9 (453.6) |
| 215/45R17 | 24.6x8.5R17 | 24.6" (625.3 mm) | 8.5" (215 mm) | 17" x 7.0-8.0" | 3.8" (96.8 mm) | 77.3" (1964.4 mm) | 819.2 (509.1) |
| 225/50R17 | 25.9x8.9R17 | 25.9" (656.8 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 4.4" (112.5 mm) | 81.2" (2063.4 mm) | 779.9 (484.6) |
32-Inch Tires On 17-Inch Rims
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 235/85R17 | 32.7x9.3R17 | 32.7" (831.3 mm) | 9.3" (235 mm) | 17" x 6.0-8.0" | 7.9" (199.8 mm) | 102.8" (2611.6 mm) | 616.2 (382.9) |
| 255/75R17 | 32.1x10R17 | 32.1" (814.3 mm) | 10" (255 mm) | 17" x 6.5-8.5" | 7.5" (191.3 mm) | 100.7" (2558.2 mm) | 629.1 (390.9) |
| 275/70R17 | 32.2x10.8R17 | 32.2" (816.8 mm) | 10.8" (275 mm) | 17" x 7.0-8.5" | 7.6" (192.5 mm) | 101" (2566.1 mm) | 627.2 (389.7) |
| 285/70R17 | 32.7x11.2R17 | 32.7" (830.8 mm) | 11.2" (285 mm) | 17" x 7.5-9.0" | 7.9" (199.5 mm) | 102.8" (2610 mm) | 616.6 (383.1) |
| 305/65R17 | 32.6x12R17 | 32.6" (828.3 mm) | 12" (305 mm) | 17" x 8.5-11.0" | 7.8" (198.3 mm) | 102.4" (2602.2 mm) | 618.5 (384.3) |
33-Inch Tires On 17-Inch Rims
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 255/80R17 | 33.1x10R17 | 33.1" (839.8 mm) | 10" (255 mm) | 17" x 6.5-8.5" | 8" (204 mm) | 103.9" (2638.3 mm) | 610 (379) |
| 285/75R17 | 33.8x11.2R17 | 33.8" (859.3 mm) | 11.2" (285 mm) | 17" x 7.5-9.5" | 8.4" (213.8 mm) | 106.3" (2699.6 mm) | 596.1 (370.4) |
| 295/70R17 | 33.3x11.6R17 | 33.3" (844.8 mm) | 11.6" (295 mm) | 17" x 8.0-9.5" | 8.1" (206.5 mm) | 104.5" (2654 mm) | 606.4 (376.8) |
| 305/70R17 | 33.8x12R17 | 33.8" (858.8 mm) | 12" (305 mm) | 17" x 8.0-9.5" | 8.4" (213.5 mm) | 106.2" (2698 mm) | 596.5 (370.6) |
Tire Size Chart For 17-Inch Rims
| Tire Size (mm) | Tire Size (Inch) | Overall Diameter | Tread With | Rim Size (H x W) | Sidewall Height | Circumference | Revs/mile (km) |
|---|---|---|---|---|---|---|---|
| 115/95R17 | 25.6x4.5R17 | 25.6" (650.3 mm) | 4.5" (115 mm) | 17" x n/a | 4.3" (109.3 mm) | 80.4" (2043 mm) | 787.7 (489.5) |
| 125/70R17 | 23.9x4.9R17 | 23.9" (606.8 mm) | 4.9" (125 mm) | 17" x n/a | 3.4" (87.5 mm) | 75.1" (1906.3 mm) | 844.2 (524.6) |
| 125/80R17 | 24.9x4.9R17 | 24.9" (631.8 mm) | 4.9" (125 mm) | 17" x 3.0-4.0" | 3.9" (100 mm) | 78.1" (1984.9 mm) | 810.8 (503.8) |
| 135/70R17 | 24.4x5.3R17 | 24.4" (620.8 mm) | 5.3" (135 mm) | 17" x n/a | 3.7" (94.5 mm) | 76.8" (1950.3 mm) | 825.2 (512.7) |
| 135/80R17 | 25.5x5.3R17 | 25.5" (647.8 mm) | 5.3" (135 mm) | 17" x n/a | 4.3" (108 mm) | 80.1" (2035.1 mm) | 790.8 (491.4) |
| 135/90R17 | 26.6x5.3R17 | 26.6" (674.8 mm) | 5.3" (135 mm) | 17" x n/a | 4.8" (121.5 mm) | 83.5" (2119.9 mm) | 759.1 (471.7) |
| 145/70R17 | 25x5.7R17 | 25" (634.8 mm) | 5.7" (145 mm) | 17" x n/a | 4" (101.5 mm) | 78.5" (1994.3 mm) | 807 (501.4) |
| 145/80R17 | 26.1x5.7R17 | 26.1" (663.8 mm) | 5.7" (145 mm) | 17" x n/a | 4.6" (116 mm) | 82.1" (2085.4 mm) | 771.7 (479.5) |
| 145/90R17 | 27.3x5.7R17 | 27.3" (692.8 mm) | 5.7" (145 mm) | 17" x n/a | 5.1" (130.5 mm) | 85.7" (2176.5 mm) | 739.4 (459.5) |
| 155/70R17 | 25.5x6.1R17 | 25.5" (648.8 mm) | 6.1" (155 mm) | 17" x n/a | 4.3" (108.5 mm) | 80.2" (2038.3 mm) | 789.6 (490.6) |
| 155/80R17 | 26.8x6.1R17 | 26.8" (679.8 mm) | 6.1" (155 mm) | 17" x n/a | 4.9" (124 mm) | 84.1" (2135.7 mm) | 753.6 (468.2) |
| 155/90R17 | 28x6.1R17 | 28" (710.8 mm) | 6.1" (155 mm) | 17" x n/a | 5.5" (139.5 mm) | 87.9" (2233 mm) | 720.7 (447.8) |
| 165/40R17 | 22.2x6.5R17 | 22.2" (563.8 mm) | 6.5" (165 mm) | 17" x n/a | 2.6" (66 mm) | 69.7" (1771.2 mm) | 908.6 (564.6) |
| 165/45R17 | 22.8x6.5R17 | 22.8" (580.3 mm) | 6.5" (165 mm) | 17" x n/a | 2.9" (74.3 mm) | 71.8" (1823.1 mm) | 882.8 (548.5) |
| 165/70R17 | 26.1x6.5R17 | 26.1" (662.8 mm) | 6.5" (165 mm) | 17" x n/a | 4.5" (115.5 mm) | 82" (2082.2 mm) | 772.9 (480.3) |
| 165/80R17 | 27.4x6.5R17 | 27.4" (695.8 mm) | 6.5" (165 mm) | 17" x n/a | 5.2" (132 mm) | 86.1" (2185.9 mm) | 736.2 (457.5) |
| 165/90R17 | 28.7x6.5R17 | 28.7" (728.8 mm) | 6.5" (165 mm) | 17" x n/a | 5.8" (148.5 mm) | 90.1" (2289.6 mm) | 702.9 (436.8) |
| 175/55R17 | 24.6x6.9R17 | 24.6" (624.3 mm) | 6.9" (175 mm) | 17" x 5.0-6.0" | 3.8" (96.3 mm) | 77.2" (1961.3 mm) | 820.6 (509.9) |
| 175/90R17 | 29.4x6.9R17 | 29.4" (746.8 mm) | 6.9" (175 mm) | 17" x n/a | 6.2" (157.5 mm) | 92.4" (2346.1 mm) | 686 (426.2) |
| 185/35R17 | 22.1x7.3R17 | 22.1" (561.3 mm) | 7.3" (185 mm) | 17" x n/a | 2.5" (64.8 mm) | 69.4" (1763.4 mm) | 912.6 (567.1) |
| 185/50R17 | 24.3x7.3R17 | 24.3" (616.8 mm) | 7.3" (185 mm) | 17" x 4.5-6.0" | 3.6" (92.5 mm) | 76.3" (1937.7 mm) | 830.5 (516.1) |
| 185/60R17 | 25.7x7.3R17 | 25.7" (653.8 mm) | 7.3" (185 mm) | 17" x n/a | 4.4" (111 mm) | 80.9" (2054 mm) | 783.5 (486.9) |
| 195/40R17 | 23.1x7.7R17 | 23.1" (587.8 mm) | 7.7" (195 mm) | 17" x 6.5-7.5" | 3.1" (78 mm) | 72.7" (1846.6 mm) | 871.5 (541.5) |
| 195/45R17 | 23.9x7.7R17 | 23.9" (607.3 mm) | 7.7" (195 mm) | 17" x 6.0-7.5" | 3.5" (87.8 mm) | 75.1" (1907.9 mm) | 843.5 (524.1) |
| 195/50R17 | 24.7x7.7R17 | 24.7" (626.8 mm) | 7.7" (195 mm) | 17" x n/a | 3.8" (97.5 mm) | 77.5" (1969.2 mm) | 817.3 (507.8) |
| 195/55R17 | 25.4x7.7R17 | 25.4" (646.3 mm) | 7.7" (195 mm) | 17" x 5.5-7.0" | 4.2" (107.3 mm) | 79.9" (2030.4 mm) | 792.6 (492.5) |
| 205/40R17 | 23.5x8.1R17 | 23.5" (595.8 mm) | 8.1" (205 mm) | 17" x 7.0-8.0" | 3.2" (82 mm) | 73.7" (1871.8 mm) | 859.8 (534.3) |
| 205/45R17 | 24.3x8.1R17 | 24.3" (616.3 mm) | 8.1" (205 mm) | 17" x 6.5-7.5" | 3.6" (92.3 mm) | 76.2" (1936.2 mm) | 831.2 (516.5) |
| 205/50R17 | 25.1x8.1R17 | 25.1" (636.8 mm) | 8.1" (205 mm) | 17" x 5.5-7.5" | 4" (102.5 mm) | 78.8" (2000.6 mm) | 804.4 (499.9) |
| 205/55R17 | 25.9x8.1R17 | 25.9" (657.3 mm) | 8.1" (205 mm) | 17" x 5.5-7.5" | 4.4" (112.8 mm) | 81.3" (2065 mm) | 779.4 (484.3) |
| 205/60R17 | 26.7x8.1R17 | 26.7" (677.8 mm) | 8.1" (205 mm) | 17" x 5.5-7.5" | 4.8" (123 mm) | 83.8" (2129.4 mm) | 755.8 (469.6) |
| 205/65R17 | 27.5x8.1R17 | 27.5" (698.3 mm) | 8.1" (205 mm) | 17" x 5.5-7.5" | 5.2" (133.3 mm) | 86.4" (2193.8 mm) | 733.6 (455.8) |
| 215/35R17 | 22.9x8.5R17 | 22.9" (582.3 mm) | 8.5" (215 mm) | 17" x 7.0-8.5" | 3" (75.3 mm) | 72" (1829.3 mm) | 879.7 (546.6) |
| 215/40R17 | 23.8x8.5R17 | 23.8" (603.8 mm) | 8.5" (215 mm) | 17" x 7.0-8.5" | 3.4" (86 mm) | 74.7" (1896.9 mm) | 848.4 (527.2) |
| 215/45R17 | 24.6x8.5R17 | 24.6" (625.3 mm) | 8.5" (215 mm) | 17" x 7.0-8.0" | 3.8" (96.8 mm) | 77.3" (1964.4 mm) | 819.2 (509.1) |
| 215/50R17 | 25.5x8.5R17 | 25.5" (646.8 mm) | 8.5" (215 mm) | 17" x 6.0-7.5" | 4.2" (107.5 mm) | 80" (2032 mm) | 792 (492.1) |
| 215/55R17 | 26.3x8.5R17 | 26.3" (668.3 mm) | 8.5" (215 mm) | 17" x 6.0-7.5" | 4.7" (118.3 mm) | 82.7" (2099.5 mm) | 766.5 (476.3) |
| 215/60R17 | 27.2x8.5R17 | 27.2" (689.8 mm) | 8.5" (215 mm) | 17" x 6.0-7.5" | 5.1" (129 mm) | 85.3" (2167.1 mm) | 742.6 (461.5) |
| 215/65R17 | 28x8.5R17 | 28" (711.3 mm) | 8.5" (215 mm) | 17" x 6.0-7.5" | 5.5" (139.8 mm) | 88" (2234.6 mm) | 720.2 (447.5) |
| 215/70R17 | 28.9x8.5R17 | 28.9" (732.8 mm) | 8.5" (215 mm) | 17" x 5.5-7.0" | 5.9" (150.5 mm) | 90.6" (2302.2 mm) | 699.1 (434.4) |
| 225/35R17 | 23.2x8.9R17 | 23.2" (589.3 mm) | 8.9" (225 mm) | 17" x 7.5-9.0" | 3.1" (78.8 mm) | 72.9" (1851.3 mm) | 869.3 (540.1) |
| 225/40R17 | 24.1x8.9R17 | 24.1" (611.8 mm) | 8.9" (225 mm) | 17" x 7.5-9.0" | 3.5" (90 mm) | 75.7" (1922 mm) | 837.3 (520.3) |
| 225/45R17 | 25x8.9R17 | 25" (634.3 mm) | 8.9" (225 mm) | 17" x 7.0-8.5" | 4" (101.3 mm) | 78.5" (1992.7 mm) | 807.6 (501.8) |
| 225/50R17 | 25.9x8.9R17 | 25.9" (656.8 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 4.4" (112.5 mm) | 81.2" (2063.4 mm) | 779.9 (484.6) |
| 225/55R17 | 26.7x8.9R17 | 26.7" (679.3 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 4.9" (123.8 mm) | 84" (2134.1 mm) | 754.1 (468.6) |
| 225/60R17 | 27.6x8.9R17 | 27.6" (701.8 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 5.3" (135 mm) | 86.8" (2204.8 mm) | 729.9 (453.6) |
| 225/65R17 | 28.5x8.9R17 | 28.5" (724.3 mm) | 8.9" (225 mm) | 17" x 6.0-8.0" | 5.8" (146.3 mm) | 89.6" (2275.5 mm) | 707.3 (439.5) |
| 225/70R17 | 29.4x8.9R17 | 29.4" (746.8 mm) | 8.9" (225 mm) | 17" x 6.0-7.5" | 6.2" (157.5 mm) | 92.4" (2346.1 mm) | 686 (426.2) |
| 225/75R17 | 30.3x8.9R17 | 30.3" (769.3 mm) | 8.9" (225 mm) | 17" x 6.0-7.5" | 6.6" (168.8 mm) | 95.2" (2416.8 mm) | 665.9 (413.8) |
| 235/40R17 | 24.4x9.3R17 | 24.4" (619.8 mm) | 9.3" (235 mm) | 17" x 8.0-9.5" | 3.7" (94 mm) | 76.7" (1947.2 mm) | 826.5 (513.6) |
| 235/45R17 | 25.3x9.3R17 | 25.3" (643.3 mm) | 9.3" (235 mm) | 17" x 7.5-9.0" | 4.2" (105.8 mm) | 79.6" (2021 mm) | 796.3 (494.8) |
| 235/50R17 | 26.3x9.3R17 | 26.3" (666.8 mm) | 9.3" (235 mm) | 17" x 6.5-8.5" | 4.6" (117.5 mm) | 82.5" (2094.8 mm) | 768.3 (477.4) |
| 235/55R17 | 27.2x9.3R17 | 27.2" (690.3 mm) | 9.3" (235 mm) | 17" x 6.5-8.5" | 5.1" (129.3 mm) | 85.4" (2168.6 mm) | 742.1 (461.1) |
| 235/60R17 | 28.1x9.3R17 | 28.1" (713.8 mm) | 9.3" (235 mm) | 17" x 6.5-8.5" | 5.6" (141 mm) | 88.3" (2242.5 mm) | 717.7 (445.9) |
| 235/65R17 | 29x9.3R17 | 29" (737.3 mm) | 9.3" (235 mm) | 17" x 6.5-8.5" | 6" (152.8 mm) | 91.2" (2316.3 mm) | 694.8 (431.7) |
| 235/70R17 | 30x9.3R17 | 30" (760.8 mm) | 9.3" (235 mm) | 17" x 6.0-8.0" | 6.5" (164.5 mm) | 94.1" (2390.1 mm) | 673.3 (418.4) |
| 235/75R17 | 30.9x9.3R17 | 30.9" (784.3 mm) | 9.3" (235 mm) | 17" x 6.0-8.0" | 6.9" (176.3 mm) | 97" (2464 mm) | 653.2 (405.9) |
| 235/80R17 | 31.8x9.3R17 | 31.8" (807.8 mm) | 9.3" (235 mm) | 17" x 6.0-7.5" | 7.4" (188 mm) | 99.9" (2537.8 mm) | 634.2 (394) |
| 235/85R17 | 32.7x9.3R17 | 32.7" (831.3 mm) | 9.3" (235 mm) | 17" x 6.0-8.0" | 7.9" (199.8 mm) | 102.8" (2611.6 mm) | 616.2 (382.9) |
| 245/35R17 | 23.8x9.6R17 | 23.8" (603.3 mm) | 9.6" (245 mm) | 17" x 8.0-9.5" | 3.4" (85.8 mm) | 74.6" (1895.3 mm) | 849.1 (527.6) |
| 245/40R17 | 24.7x9.6R17 | 24.7" (627.8 mm) | 9.6" (245 mm) | 17" x 8.0-9.5" | 3.9" (98 mm) | 77.6" (1972.3 mm) | 816 (507) |
| 245/45R17 | 25.7x9.6R17 | 25.7" (652.3 mm) | 9.6" (245 mm) | 17" x 7.5-9.0" | 4.3" (110.3 mm) | 80.7" (2049.3 mm) | 785.3 (488) |
| 245/50R17 | 26.6x9.6R17 | 26.6" (676.8 mm) | 9.6" (245 mm) | 17" x 7.0-8.5" | 4.8" (122.5 mm) | 83.7" (2126.2 mm) | 756.9 (470.3) |
| 245/55R17 | 27.6x9.6R17 | 27.6" (701.3 mm) | 9.6" (245 mm) | 17" x 7.0-8.5" | 5.3" (134.8 mm) | 86.7" (2203.2 mm) | 730.5 (453.9) |
| 245/60R17 | 28.6x9.6R17 | 28.6" (725.8 mm) | 9.6" (245 mm) | 17" x 7.0-8.5" | 5.8" (147 mm) | 89.8" (2280.2 mm) | 705.8 (438.6) |
| 245/65R17 | 29.5x9.6R17 | 29.5" (750.3 mm) | 9.6" (245 mm) | 17" x 7.0-8.5" | 6.3" (159.3 mm) | 92.8" (2357.1 mm) | 682.8 (424.2) |
| 245/70R17 | 30.5x9.6R17 | 30.5" (774.8 mm) | 9.6" (245 mm) | 17" x 6.5-8.0" | 6.8" (171.5 mm) | 95.8" (2434.1 mm) | 661.2 (410.8) |
| 245/75R17 | 31.5x9.6R17 | 31.5" (799.3 mm) | 9.6" (245 mm) | 17" x 6.5-8.0" | 7.2" (183.8 mm) | 98.9" (2511.1 mm) | 640.9 (398.2) |
| 255/40R17 | 25x10R17 | 25" (635.8 mm) | 10" (255 mm) | 17" x 8.5-10.0" | 4" (102 mm) | 78.6" (1997.4 mm) | 805.7 (500.6) |
| 255/45R17 | 26x10R17 | 26" (661.3 mm) | 10" (255 mm) | 17" x 8.0-9.5" | 4.5" (114.8 mm) | 81.8" (2077.5 mm) | 774.6 (481.3) |
| 255/50R17 | 27x10R17 | 27" (686.8 mm) | 10" (255 mm) | 17" x 7.0-9.0" | 5" (127.5 mm) | 84.9" (2157.6 mm) | 745.9 (463.5) |
| 255/55R17 | 28x10R17 | 28" (712.3 mm) | 10" (255 mm) | 17" x 7.0-9.0" | 5.5" (140.3 mm) | 88.1" (2237.8 mm) | 719.2 (446.9) |
| 255/60R17 | 29x10R17 | 29" (737.8 mm) | 10" (255 mm) | 17" x 7.0-9.0" | 6" (153 mm) | 91.3" (2317.9 mm) | 694.3 (431.4) |
| 255/65R17 | 30.1x10R17 | 30.1" (763.3 mm) | 10" (255 mm) | 17" x 7.0-8.5" | 6.5" (165.8 mm) | 94.4" (2398 mm) | 671.1 (417) |
| 255/70R17 | 31.1x10R17 | 31.1" (788.8 mm) | 10" (255 mm) | 17" x 6.5-8.5" | 7" (178.5 mm) | 97.6" (2478.1 mm) | 649.4 (403.5) |
| 255/75R17 | 32.1x10R17 | 32.1" (814.3 mm) | 10" (255 mm) | 17" x 6.5-8.5" | 7.5" (191.3 mm) | 100.7" (2558.2 mm) | 629.1 (390.9) |
| 255/80R17 | 33.1x10R17 | 33.1" (839.8 mm) | 10" (255 mm) | 17" x 6.5-8.5" | 8" (204 mm) | 103.9" (2638.3 mm) | 610 (379) |
| 265/35R17 | 24.3x10.4R17 | 24.3" (617.3 mm) | 10.4" (265 mm) | 17" x 9.0-10.5" | 3.7" (92.8 mm) | 76.4" (1939.3 mm) | 829.9 (515.6) |
| 265/40R17 | 25.3x10.4R17 | 25.3" (643.8 mm) | 10.4" (265 mm) | 17" x 9.0-10.5" | 4.2" (106 mm) | 79.6" (2022.6 mm) | 795.7 (494.4) |
| 265/55R17 | 28.5x10.4R17 | 28.5" (723.3 mm) | 10.4" (265 mm) | 17" x 7.5-9.5" | 5.7" (145.8 mm) | 89.5" (2272.3 mm) | 708.2 (440.1) |
| 265/60R17 | 29.5x10.4R17 | 29.5" (749.8 mm) | 10.4" (265 mm) | 17" x 7.5-9.5" | 6.3" (159 mm) | 92.7" (2355.6 mm) | 683.2 (424.5) |
| 265/65R17 | 30.6x10.4R17 | 30.6" (776.3 mm) | 10.4" (265 mm) | 17" x 7.5-9.5" | 6.8" (172.3 mm) | 96" (2438.8 mm) | 659.9 (410) |
| 265/70R17 | 31.6x10.4R17 | 31.6" (802.8 mm) | 10.4" (265 mm) | 17" x 7.0-9.0" | 7.3" (185.5 mm) | 99.3" (2522.1 mm) | 638.1 (396.5) |
| 275/35R17 | 24.6x10.8R17 | 24.6" (624.3 mm) | 10.8" (275 mm) | 17" x 9.0-11.0" | 3.8" (96.3 mm) | 77.2" (1961.3 mm) | 820.6 (509.9) |
| 275/40R17 | 25.7x10.8R17 | 25.7" (651.8 mm) | 10.8" (275 mm) | 17" x 9.0-11.0" | 4.3" (110 mm) | 80.6" (2047.7 mm) | 785.9 (488.4) |
| 275/50R17 | 27.8x10.8R17 | 27.8" (706.8 mm) | 10.8" (275 mm) | 17" x 7.5-9.5" | 5.4" (137.5 mm) | 87.4" (2220.5 mm) | 724.8 (450.4) |
| 275/55R17 | 28.9x10.8R17 | 28.9" (734.3 mm) | 10.8" (275 mm) | 17" x 7.5-9.5" | 6" (151.3 mm) | 90.8" (2306.9 mm) | 697.6 (433.5) |
| 275/60R17 | 30x10.8R17 | 30" (761.8 mm) | 10.8" (275 mm) | 17" x 7.5-9.5" | 6.5" (165 mm) | 94.2" (2393.3 mm) | 672.4 (417.8) |
| 275/65R17 | 31.1x10.8R17 | 31.1" (789.3 mm) | 10.8" (275 mm) | 17" x 7.5-9.5" | 7" (178.8 mm) | 97.6" (2479.7 mm) | 649 (403.3) |
| 275/70R17 | 32.2x10.8R17 | 32.2" (816.8 mm) | 10.8" (275 mm) | 17" x 7.0-8.5" | 7.6" (192.5 mm) | 101" (2566.1 mm) | 627.2 (389.7) |
| 275/80R17 | 34.3x10.8R17 | 34.3" (871.8 mm) | 10.8" (275 mm) | 17" x n/a | 8.7" (220 mm) | 107.8" (2738.8 mm) | 587.6 (365.1) |
| 285/35R17 | 24.9x11.2R17 | 24.9" (631.3 mm) | 11.2" (285 mm) | 17" x n/a | 3.9" (99.8 mm) | 78.1" (1983.3 mm) | 811.5 (504.2) |
| 285/40R17 | 26x11.2R17 | 26" (659.8 mm) | 11.2" (285 mm) | 17" x 9.5-11.0" | 4.5" (114 mm) | 81.6" (2072.8 mm) | 776.4 (482.4) |
| 285/60R17 | 30.5x11.2R17 | 30.5" (773.8 mm) | 11.2" (285 mm) | 17" x 8.0-10.0" | 6.7" (171 mm) | 95.7" (2431 mm) | 662 (411.4) |
| 285/65R17 | 31.6x11.2R17 | 31.6" (802.3 mm) | 11.2" (285 mm) | 17" x 8.0-10.0" | 7.3" (185.3 mm) | 99.2" (2520.5 mm) | 638.5 (396.7) |
| 285/70R17 | 32.7x11.2R17 | 32.7" (830.8 mm) | 11.2" (285 mm) | 17" x 7.5-9.0" | 7.9" (199.5 mm) | 102.8" (2610 mm) | 616.6 (383.1) |
| 285/75R17 | 33.8x11.2R17 | 33.8" (859.3 mm) | 11.2" (285 mm) | 17" x 7.5-9.5" | 8.4" (213.8 mm) | 106.3" (2699.6 mm) | 596.1 (370.4) |
| 295/35R17 | 25.1x11.6R17 | 25.1" (638.3 mm) | 11.6" (295 mm) | 17" x n/a | 4.1" (103.3 mm) | 78.9" (2005.3 mm) | 802.6 (498.7) |
| 295/40R17 | 26.3x11.6R17 | 26.3" (667.8 mm) | 11.6" (295 mm) | 17" x 10.0-11.5" | 4.6" (118 mm) | 82.6" (2098 mm) | 767.1 (476.7) |
| 295/45R17 | 27.5x11.6R17 | 27.5" (697.3 mm) | 11.6" (295 mm) | 17" x n/a | 5.2" (132.8 mm) | 86.2" (2190.6 mm) | 734.6 (456.5) |
| 295/70R17 | 33.3x11.6R17 | 33.3" (844.8 mm) | 11.6" (295 mm) | 17" x 8.0-9.5" | 8.1" (206.5 mm) | 104.5" (2654 mm) | 606.4 (376.8) |
| 295/75R17 | 34.4x11.6R17 | 34.4" (874.3 mm) | 11.6" (295 mm) | 17" x n/a | 8.7" (221.3 mm) | 108.1" (2746.7 mm) | 585.9 (364.1) |
| 305/35R17 | 25.4x12R17 | 25.4" (645.3 mm) | 12" (305 mm) | 17" x n/a | 4.2" (106.8 mm) | 79.8" (2027.3 mm) | 793.8 (493.3) |
| 305/45R17 | 27.8x12R17 | 27.8" (706.3 mm) | 12" (305 mm) | 17" x 9.5-11.5" | 5.4" (137.3 mm) | 87.4" (2218.9 mm) | 725.3 (450.7) |
| 305/60R17 | 31.4x12R17 | 31.4" (797.8 mm) | 12" (305 mm) | 17" x n/a | 7.2" (183 mm) | 98.7" (2506.4 mm) | 642.1 (399) |
| 305/65R17 | 32.6x12R17 | 32.6" (828.3 mm) | 12" (305 mm) | 17" x 8.5-11.0" | 7.8" (198.3 mm) | 102.4" (2602.2 mm) | 618.5 (384.3) |
| 305/70R17 | 33.8x12R17 | 33.8" (858.8 mm) | 12" (305 mm) | 17" x 8.0-9.5" | 8.4" (213.5 mm) | 106.2" (2698 mm) | 596.5 (370.6) |
| 315/35R17 | 25.7x12.4R17 | 25.7" (652.3 mm) | 12.4" (315 mm) | 17" x 10.5-12.5" | 4.3" (110.3 mm) | 80.7" (2049.3 mm) | 785.3 (488) |
| 315/45R17 | 28.2x12.4R17 | 28.2" (715.3 mm) | 12.4" (315 mm) | 17" x 10.0-12.0" | 5.6" (141.8 mm) | 88.5" (2247.2 mm) | 716.2 (445) |
| 315/70R17 | 34.4x12.4R17 | 34.4" (872.8 mm) | 12.4" (315 mm) | 17" x 8.0-10.5" | 8.7" (220.5 mm) | 108" (2742 mm) | 586.9 (364.7) |
| 325/70R17 | 34.9x12.8R17 | 34.9" (886.8 mm) | 12.8" (325 mm) | 17" x 8.5-10.0" | 9" (227.5 mm) | 109.7" (2786 mm) | 577.7 (358.9) |
| 335/35R17 | 26.2x13.2R17 | 26.2" (666.3 mm) | 13.2" (335 mm) | 17" x 11.0-13.0" | 4.6" (117.3 mm) | 82.4" (2093.2 mm) | 768.8 (477.7) |
| 345/40R17 | 27.9x13.6R17 | 27.9" (707.8 mm) | 13.6" (345 mm) | 17" x 11.5-13.5" | 5.4" (138 mm) | 87.5" (2223.6 mm) | 723.7 (449.7) |
| 345/55R17 | 31.9x13.6R17 | 31.9" (811.3 mm) | 13.6" (345 mm) | 17" x n/a | 7.5" (189.8 mm) | 100.3" (2548.8 mm) | 631.4 (392.3) |
| 355/70R17 | 36.6x14R17 | 36.6" (928.8 mm) | 14" (355 mm) | 17" x 9.5-11.0" | 9.8" (248.5 mm) | 114.9" (2917.9 mm) | 551.5 (342.7) |
